1. Statutory provision for setting up of crisis groups at National state , District and locations having major accident hazards .
2. CCG is headed by secretary to govt. Of India , Dept.of Environment and forests .
3. Duty of CCG is to develop Crisis Alert system.
4. State crisis group is headed by chief secretary with following functions.
4.1. Reviewing district off-site Emergency Plan and send report to CCG.
4.2. Assist state government in managing chemical accidents at site .
4.3. Assist state government in planning preparedness and mitigation of major chemical accident
4.4. Continuous monitoring of Post Accident situations.
4.5. Review progress reports submitted by district Crisis Group.
4.6. Publish list of experts concerned with Management of chemical accidents.
5. District Crisis Group is headed by District Collector.
6. The function include .....
6.1.Assist in preparing district off-site Emergency Plan.
6.2. Review of on-site emergency plans of major accident hazard installations.
6.3.Assist district Administration in management of chemical accidents.
6.4. Continuous monitoring of chemical accidents.
6.5. Ensure Continuous information flow to CCG and SCG regarding accidents and mitigation measures.
6.6. Forward chemical accident within fortnight .
6.7. Conduct atleast one full mock drill.
7. Local Crisis Group (LCG) is each industrial pocket having major accident hazards headed by sub-divisional magistrate .
8. The functions include ...
8.1. Prepare local emergency plan for the pocket .
8.2. Train personnel involved in chemical accident management.
8.3. Aware public about remedies and preparedness for accident.
8.4. Conduct mock drill atleast once in six months
8.5. Respond public enquiries on the subject.
Thursday, 25 May 2017
SALIENT PROVISIONS OF CHEMICAL ACCIDENT ( EMERGENCY PLANNING, PROCEDURE AND RESPONSE )RULES ,1996 (AMENDED 1999)
Salient Provisions of Central Motor Vehicle Rules
1. The carriage transporting hazardous goods shall display a distinct mark of the class lable of the dangerous goods with prescribed mode , class label size , colour code etc .
2. Emergency information panel shall be displayed in the carriage used for transportation of hazardous goods .
3. The consigner shall supply adequate safety information to the transporter and transporter shall make all the necessary information for sale transport available .
4. The driver of the carriage must have sufficient understanding of the carriage from the owner of the carriage in writing .
5. The driver shall observe all precautions all the times in case of an accident and report to the nearest police station
Salient Provisions of Manufactures , Storage , Import , Hazardous Chemical Rules , 1989
1.List of 684 hazardous chemical notified.
2. Isolated storage of hazardous chemicals dealt separately
3. Different authorities identified for regulation at various stage of handling of hazardous chemicals.
4. Three level of control depending on hazard potential
5. Site approval of isolated storage risk Analysis.
6. Third party safety audit every year
7. Preparation of on-site & off-white emergency plans
8. Regulatory agencies - Inspectorate of factories ,SPC Board , District collector controller of Import & Exports , controller of explosives.
When conducting an illness and injury record analysis , how long might it take to collect information from a site
A . 1 Year
B. 1 to 7 months
C. 1 months
D. 3 to 5 years
A documents that lists items involved in an accident, the way in which each item can fail, the effects of the failure and means of detection and action is an example of
1.Fault tree analysis
2. Failure mode effect Analysis
3. Hazards identification and risk assessment
4. Job safety analysis
FIRE - Anotomy and its classification
Fire is an exothermic chemical reaction in which combustible material combines with oxygen in the atmosphere to give out heat and flame. But once fire has begun, the heat produced may often be sufficient to support or even accelerate the process. The materials involved in the combustion process may be in solid, liquid or gaseous state. They are also identified as two or three-dimensional
Two-dimensional fires are those where fire and fuel are on a single plane or flat surface. Ground fire or trench fire fall in this group of fires.Three - dimensional fires are complicated fires of falling liquid streams or fuel under pressure escaping from a container. Fire resulting from leak of transformer oil falls under this category.
Fire is not happen by their own self. It require some elements,Four factors/ Elements must be required in order before combustion occurs.
Heat-Sufficient to raise the temperature to ignition point Oxygen at sufficient quantity FuelChemical Chain reaction of above three mixtures.
These Four elements may be represented in the form of a Tetrahedron.
Just as removal of one or more sides of a tetrahedron causes its breakdown, the removal of one or more factors causes the fire to cease.
Stages of Fire
The Fire Triangle/Fire Tetrahedron
Except explosion, most fires have humble starting and grow through the following four stages of combustions:
Incipient stage: At this stage decomposition is occurring at the surface of the fuel due to the influence of some form of heat. Products of combustion given off at this stage are invisible to the eye.
Smouldering Stage: At this Stage, up to 10% of the decomposing products released at the surface of the fuel are visible.
Flaming Stage: Vapours from the decomposing fuel have ignited and are at the stage where flames are self-propagating.
Heat stage: At this stage the burning has progressed to the point where the fire is still small but generating sufficient heat to warm the air immediately around the fire sending warm products of combustion upwards by convection. The above principle is used for the selection of fire detectors.
Classification of Fire as per Bureau of Indian Standards (BIS)
Combustible substance can be present in three states - solid, liquid and gaseous state. The burning of most materials produces a flame, this occurs when vapour or gas given off by the liquid or solid materials is ignited. Depending upon the nature and state of the burning material, fires are generally classified into A, B, C or D type.
Class - A: Fire
These are fires involving solid materials, normally of carbon compounds in which combustion.
Generally occurs with the formation of glowing embers. These types of fires are most common.Examples of Class A - fires are fires involving wood, rags, paper, plastic coal etc.
Class - B: Fire
These fires involve flammable liquids or liquefiable solids. That is, fires occurring in vapour-air mixture over the surface of flammable liquids such as gasoline, oils, paints & thinners. These types of fires occur in storage tanks and chemical storages.
Class - C: Fire
These are fires involving liquefiable gases like propane, butane, LPG, H2, etc.
Class - D: Fire
These are fires that occur in combustible metals such as magnesium, Titanium, Sodium etc. For Controlling such fires, special extinguishing agents/equipment and techniques are to be used.
Tuesday, 23 May 2017
CARBON-MONOXIDE(CO)
Ergonomics play an important role in all of the following except
1. Chemical related accidents
2. Strains
3. Repetitve motion disorders
4. Injuries
Monday, 22 May 2017
Which of the following is true regarding documents and audits ?
1. Documentation is usually only reviewed in audits with an unlimited scope .
2. Because of the different individual record -keeping styles documentation is rarely helpful in audits
3. Documentation should be reviewed in nearly every audits
4. Unless an audit is meant to specifically review record keeping, documentation is not particularly helpful in the context of an audits
Which of the following is excluded from the toxic substance control act ?
1. Asbestos
2. Radon
3. Lead-bases paints
4. Pesticides
Sunday, 21 May 2017
Precautions to be taken during and after the Chemical (Industrial) Accidents
Wednesday, 10 May 2017
Acetylene cylinders are filled with porous packing material to
Tuesday, 9 May 2017
FOR SAFETY'S - DO SOMETHING
Establishing a safe working Environment
Saturday, 7 January 2017
Did you know that what is the Minimum Ground Clearance As Per IE-1956(Rule 77) ?
Minimum
Ground Clearance As Per IE-1956(Rule 77)
|
|
Voltage in KV
|
To ground in mm
|
132
|
6.10
|
220
|
7.00
|
400
|
8.84
|
800
|
12.40
|
Which section of Factories act states every occupier is to prepare On-site Emergency Plan and detailed disaster control measures for his factory?
1) Section 41(B)(4)
2) Section 40B
3) Section 7A
4) Section 39
Answer :
1) Section 41(B)(4)
ACCORDING TO INDIAN ELECTRICITY RULE 77 THE MINIMUM CLEARANCE ABOVE THE GROUND OF HE LOWEST CONDUCTOR FOR LOW VOLTAGE LINE ACROSS A STREET SHOULD BE :
- No conductor of an overhead line, including service lines, erected across a street shall at any part thereof be at a height of less than:
- For low and medium voltage lines 5.8 meters
- For high voltage lines 6.1 meters
- No conductor of an overhead line, including service lines, erected along any street shall at any part thereof be at a height less than:
- For low and medium voltage lines 5.5 meters
- For high voltage lines 5.8 meters
- No conductor of in overhead line including service lines erected elsewhere than along or across any street shall be at a height less than:
- For low, medium and high voltages lines=4.6 meters.
- For a low, medium and high voltage=4.0 meters.
- For high voltage lines above 11,000 volts=5.2 meters.
- For extra-high voltage lines, the clearance above ground shall not be less than 5.2 meters plus 0.3 meters for every 33,000 volts or part thereof by which the voltage of the line exceeds 33,000 volts.
